BW9951
Dual-Port USB 3.2 10 Gbps Redriver
BW9951 is a low-power 2-port 10 Gbps linear redriver. It is compliant with the USB 3.2 specification. BW9951 provides adjustable equalizer, DC gain controller to compensate for the channel loss, and extends the length and enables the systems to pass USB compliance. The device optimizes performance when USB signals travel across PCB and cables, signal integrity degrades due to loss and inter-symbol interference.
BW9951 offers single supply voltage 3.3V with ultra-low power consumption. Each channel operates independently. The advanced power management of BW9951 can consume ultra-low power when the channel is idle for a longer time.
All available packages for BW9951 are listed in the following table.
BW9951 offers single supply voltage 3.3V with ultra-low power consumption. Each channel operates independently. The advanced power management of BW9951 can consume ultra-low power when the channel is idle for a longer time.
All available packages for BW9951 are listed in the following table.
|
Product Series
|
Package Type
|
|---|---|
|
BW9951
|
QFN 42
|
|
BW9951E
|
QFN 34
|
|
BW9951F
|
QFN 32
|
- Compliant with USB 3.2 Gen1 / Gen2 Specification
- Four 10 Gbps differential signal pairs
- 4-level selectable Equalization / flat gain
- Adjustable receiver equalization
- Adjustable flat gain
- Advanced power management mode (each port)
- Active mode: 300 mW
- Sleep mode: <1 mW
- Disconnect mode: 0.6 mW
- Single supply voltage: 3.3V
- Applications
- Desktop and notebook PC
- Cellular phones
- Tablet
- TVs
- Active cable
- Docking stations
BW9951
